Controllers
Single Axis Tracking Antenna Controller - RC1500
The RC1500 is a single axis inclined orbit satellite tracking antenna controller which is designed to interface to antennas powered by 36 volt DC actuators with built-in limit switches and pulse type position sensors. If the beam width of the antenna is much greater than the width of the pattern of the satellite’s apparent motion single axis tracking of inclined orbit satellites can be successfully implemented. The RC1500 can either be used in conjunction with a steerable antenna whose plane of movement is aligned with the long dimension of the narrow figure eight pattern of the satellite’s apparent motion or with fixed antennas which employ a steerable feed assembly. The RC1500 offers the following features:
• An intuitive user interface based on a 2 by 16 liquid crystal display and a 16 key keypad.
• Interfaces with pulse based position sensors - reed switch, Hall effect, or optical.
• Servo based polarization control. An optional daughter board, designated RC2KPOL, can interface with a 5 to 24
volt DC powered rotating equipped with a potentiometer for position feedback.
• Serial communications via an RS-422 port. The RC1500 uses the industry standard SA Bus protocol.
Rack Mounting (2 rack units high), 115/230 VAC Switch Selectable Power Input
Dual Axis Antenna Controller - RC2000A
RC2000A antenna controller is designed to interface with dual axis satellite antennas which employ pulse type position sensors.
Autopilot DLM Control Softrware for Windows
Standard Features:
• Support for up to four steerable antennas and up to 16 receivers
• Schedule up to 200 daily or weekly events.
• Allows the user to customize the parameters of any transponder on any satellite (RF center frequency, IF
bandwidth, audio sub-carrier frequencies, audio bandwidth, etc)
• Enhanced Versions of AutoPilot DLM
• Support for the following receivers: SA7500/7530A/7530I/9660, Standard MT810/MT830/MT830BR/MT930B,
DX Communications DIR657A/B.
• Support for the following IRDs: Wegener DVR2000/Unity-4000, SA PowerVu 9222/9223/9225, Tiernan TDR7/60,
Motorola/GI DSR 4000/4001/4800/4810, Tandberg Alteia, Tadiran Scopus (call for availability).
• Support for the following routing switch protocols: Leitch Video, Utah Scientific, PESA, Grass Valley, Image Video,
Quintech (L Band switching).
• Support for the following video tape recorders: Sony RS-422 serial protocol, Panasonic RS-422 serial protocol,
GPI control.
Filters
ZF120 5G C-Band Filter for Simulsat & Parabolic Antennas
AZF120-5G C-Band Filter is carefully designed to strongly reject out-of-band interference (above 4200 MHz and below 3820 MHz) with minimum insertion loss.
This interference is responsible for distorting both digital and analog
signals.
ZF150 C-Band Radar Bandpass Filter for Simulsat & Parabolic Antennas
ATCi C-Band TVRO Interference Filter for Marine and Altimeter Interference Frequencies (3.4-4.2 GHz)
Extended Frequency, (Slim Profile - Ideal for Simulsat Multibeam Antenna)
ZF200 C-Band Radar Bandpass Ultra Filter for Simulsat and Parabolic Antennas - Double Rejection
ATCi C-Band TVRO Interference Filter for Marine and Altimeter Interference Frequencies (3.7-4.2 GHz)
Extended Frequency, (Slim Profile - Ideal for Simulsat Multibeam Antenna)
ZF300-5G C-Band Radar Bandpass Filter for Simulsat and Parabolic Antennas - 5G Interference
ATCi C-Band TVRO Interference Filter for Marine and Altimeter Interference Frequencies (4.0-4.2 GHz)
5G Frequency Design, (Slim Profile - Ideal for Simulsat Multibeam Antenna)
Foundations
ATCi's offers a full line of Baird non-penetrating mount antenna supports. Available in the following size configurations: 2.4M, 3.1M, 3.8M, and 4.5M
2.4 Meter Non-Penetrating Mount Antenna Support System -
(5-1/2” OD Pipe, 3’ mast, 1”4x8 Ballast Trays and Pressure Pad)
3.1 Meter Non-Penetrating Mount Antenna Support System -
(5-1/2” OD Pipe, 3’ mast, ‘4x8 Ballast Trays and Pressure Pad)
3.8 Meter Non-Penetrating Mount Antenna Support System -
(5-1/2” OD Pipe, 3’ mast 5;4x8 Ballast Trays and Pressure Pad)
4.5 Meter Non-Penetrating Mount Antenna Support System -
(Mount Adaptor and 18.6’x18.6’ Ballast Tray and Pressure Pad)
LNBs
The following are featured Norsat LNBs. ATCi carries the full line of Norsat LNBs and products.
1000H Series Ku-Band Digital LNB
RP1: Redundant LNB Power Supply
Feeds / Multifeed Kits
Besides Simulsat, ATCi manufactures and sources many other antenna accessories that offer customers precision and affordability. Among them are: Parabolic Antenna Multifeed Kits, LNBS, Filters,
Non-penetrating Mount Antenna Supports, Controllers, Receivers and Splitters.
Motorized 4 Port Feed
ATCi is pleased to introduce the Motorized Version of ATCi’s 4 Port Feed originally designed for the Simulsat Multibeam Series of Antennas. Now, the same quality and performance is availale for parabolic antennas. The Motorized 4-Port Feed operates over the entire “extended” C-band frequency range from 3.4 to 4.2 GHz, and also operates over the entire commercial Ku-band frequency range of 10.95 to 12.75 GHz. The feed accommodates bandpass filters to provide the utmost in secure operation. There are no products on the market today that can match the performance and economy of the ATCi Motorized 4 Port Feed.
Parabolic Antenna Multifeed Kit
Converts most commercial parabolic antennas into systems capable of multiple satellite signal reception.
C/Ku Polorotor (2-Port)
Prime Focus, 2-Port C-Band, Rx Only
Prime Focus, 2-Port Ku-Band, Rx Only
Prime Focus, 4-Port C/Ku-Band, Rx Only
Receivers / Splitters
ATCi is proud to partner with Quintech & Evertz. The following are featured splitters products. ATCi is also pleased to offer the entire line of Quintech and Evertz splitters.
7702DA & 7703DA Active L-Band Splitters 4-way / 8-way / 16-way
